High-capacity TURBO FORCE decks deliver unsurpassed strength, a superior cut, and increased productivity in extreme mowing conditions. Equipped with a patented adjustable baffle, TURBO FORCE decks can be fine-tuned in order to conquer changing turf conditions.
High-capacity TURBO FORCE decks deliver unsurpassed strength, a superior cut, and increased productivity in extreme mowing conditions. Equipped with a patented adjustable baffle, TURBO FORCE decks can be fine-tuned in order to conquer changing turf conditions.
7-Gauge, High-Strength Steel
The TURBO FORCE deck is constructed of 7-gauge, high-strength steel which is 33% thicker and 32% higher in yield strength than ordinary 10-gauge commercial steel used in 7/10 decks. The combined effect is 75% stronger, so it easily handles the most demanding conditions and resists damage from impacts and abrasion.
Deluxe Handcrafted Seat with Arm Rests
Ultimate padding and back support with a handcrafted seat with arm rests and bullhorn logo.
Smooth, Powerful Response
The new unitized pump and wheel motor use proven commercial hydraulic components while eliminating hoses and other potential leak points. You'll get a smoother, faster response while enjoying an even more reliable machine.
Patented Adjustable Baffle
Allows operator to achieve maximum cutting performance by fine-tuning deck to conquer changing conditions, unique job sites or different times of the season. In extreme conditions, the baffle can be opened in order to conserve power and achieve faster mowing speeds.
Cast Aluminum Spindle
Cools quickly for enhanced durability and performance.
Smarter design in a bull-nose bumper
7-gauge bull-nose bumper not only protects against frontal impacts, but also contains an integral underskirt to minimize blowout of debris and dust. The bottom, leading edge of the deck is raised 1/4" (6 mm), allowing grass to stand more upright when entering the cutting chamber, ensuring a level cut.
Folding Rollover Protection System ROPS
A Rollover Protection System (ROPS), complete with seat belt, comes standard for operator protection in the case of accidental rollovers and tipovers. In situations where sufficient vertical clearance is not available, the ROPS can be temporarily unlocked and folded down.
Operator Information Center
The instrument panel includes a digital hour meter, fuel gauge, and voltage meter, as well as diagnostic indicators for the safety interlock system.
Specifications
Engine
Engine Power
26.5 hp
Engine Model
ECV749
Engine Make
Kohler
Fuel Type
Gas
Cutting system
Min Height of Cut
1 in
Max Height of Cut
5.5 in
Deck Width
52 in
Dimensions
Weight
1238 lb
Length
82 in
General
Product Use
Commercial
performance
Forward Speed
10 mph
Drive
Hydro
Parker HTE 12cc
wheels
Front Tires
13" x 6.5" - 6"
Capacities
Fuel Capacity
12 gal
features
Comfort System
Deluxe Suspension Seat
Warranty
Warranty
Confirm duration with the shop
Residential Engine Warranty
3 years
Commercial Engine Warranty
3 years
Prices and specifications may change. Read the operator’s manual before operating equipment.
