Kohler / Rehlko · Garland, Texas
CH730LP
Base-model engine information. Use the complete engine-label specification to confirm the configuration for your equipment.
- Shaft orientation
- Horizontal
- Gross power
- 21.5 (16.0) hp (kW) @ 3600 rpm
- Displacement
- 725 (44) cc (cu in)
Base-model specifications
These specifications describe the base engine, not an exact ordering configuration or a guaranteed replacement fit.
- Shaft orientation
- Horizontal
- Fuel
- Propane
- Cylinder configuration
- V-twin
- Cooling
- Air-cooled
- Gross power
- 21.5 (16.0) hp (kW) @ 3600 rpm
- Displacement
- 725 (44) cc (cu in)
- Bore
- 3.3 (83) in (mm)
- Stroke
- 2.6 (67) in (mm)
- Peak torque
- 34.0 (46.1) ft-lb (Nm) @ 2600 rpm
- Compression ratio
- 9.0:1
- Dry weight
- 108 (49) lb (kg)
- Oil capacity
- 2.0 (1.9) U.S. qt (L)
- Lubrication
- Full-pressure lubrication with full-flow filter
- Dimensions (L × W × H)
- 14 × 17.7 × 19 (356 × 450 × 483) in (mm)Length is grass screen to PTO mounting face. Width is spark plug to spark plug. Height is top of air cleaner cover to mounting feet.
Engine features
- Four-cycle
- OHV
- Cast-iron cylinder liners
- Aluminum block
- High-performance spark plugs
- Large-capacity air and oil filters
- Hydraulic valve lifters
