Kohler / Rehlko · Garland, Texas
ECH650
Base-model engine information. Use the complete engine-label specification to confirm the configuration for your equipment.
- Shaft orientation
- Horizontal
- Gross power
- 21 (15.7) hp (kW) @ 3600 rpm
- Displacement
- 694 (42.4) cc (cu in)
Base-model specifications
These specifications describe the base engine, not an exact ordering configuration or a guaranteed replacement fit.
- Shaft orientation
- Horizontal
- Fuel
- Gasoline
- Cylinder configuration
- V-twin
- Cooling
- Air-cooled
- Gross power
- 21 (15.7) hp (kW) @ 3600 rpm
- Displacement
- 694 (42.4) cc (cu in)
- Bore
- 3.2 (80) in (mm)
- Stroke
- 2.7 (69) in (mm)
- Peak torque
- 34.5 (46.8) ft-lb (Nm) @ 2600 rpm
- Compression ratio
- 8.7:1
- Dry weight
- 108 (49) lb (kg)
- Oil capacity
- 2.0 (1.9) U.S. qt (L)
- Lubrication
- Full-pressure lubrication with full-flow filter
- Dimensions with low-profile air cleaner (L × W × H)
- 14.6 × 18.2 × 18.7 (371 × 462 × 475) in (mm)Length is front to rear of engine. Width is valve cover to valve cover. Height is mounting surface to top of air cleaner.
- Dimensions with heavy-duty air cleaner (L × W × H)
- 14.8 × 18.9 × 24.5 (376 × 480 × 622) in (mm)Length is front to rear of engine. Width is valve cover to valve cover. Height is mounting surface to top of air cleaner.
Engine features
- Four-cycle
- OHV
- Cast-iron cylinder liner
- Aluminum block
- Closed-loop EFI
- High-performance spark plugs
- Hydraulic valve lifters
- Large-capacity air, fuel and oil filters
