Kohler / Rehlko · Garland, Texas
ECV834
Base-model engine information. Use the complete engine-label specification to confirm the configuration for your equipment.
- Shaft orientation
- Vertical
- Net power
- 34 (25.4) hp (kW) @ 3600 rpm
- Displacement
- 888 (54.2) cc (cu in)
Base-model specifications
These specifications describe the base engine, not an exact ordering configuration or a guaranteed replacement fit.
- Shaft orientation
- Vertical
- Fuel
- Gasoline
- Cylinder configuration
- V-twin
- Cooling
- Air-cooled
- Net power
- 34 (25.4) hp (kW) @ 3600 rpm
- Displacement
- 888 (54.2) cc (cu in)
- Bore
- 3.4 (87) in (mm)
- Stroke
- 2.9 (74.7) in (mm)
- Peak torque
- 52.3 (70.9) ft-lb (Nm) @ 3000 rpm
- Compression ratio
- 9.3:1
- Dry weight
- 134 (61) lb (kg)
- Oil capacity
- 2.0 (1.9) U.S. qt (L)
- Lubrication
- Full-pressure lubrication with full-flow filter
- Dimensions with heavy-duty air cleaner (L × W × H)
- 20.5 × 19.4 × 24.9 (520 × 494 × 632) in (mm)Length is front to rear of engine. Width is valve cover to valve cover. Height is mounting surface to top of air cleaner.
Engine features
- Four-cycle
- OHV
- Cast-iron cylinder liners
- Aluminum block
- 6-inch heavy-duty air filter
- Large-capacity air, fuel and oil filters
- Full-pressure lubrication with full-flow filter
- Oil cooler
- Chopper grass screen
